V-156-1C5
Manufacturer
Omron
Description
Switch Snap Action N.O./N.C. SPDT Hinge Roller Lever Quick Connect 15A 250VAC 250VDC 1.23N Screw Mount
Datasheet
DownloadProduct Attributes
Type
Actuator Material
Contact Current Rating
Contact Material
Current Rating
Depth
Differential Travel
Electrical Life
Housing Material
Length
Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Mechanical Life
Min Operating Temperature
Mount
Number of Positions
Operating Force
Operating Position
Orientation
Overtravel
Pretravel
Radiation Hardening
Ratings
REACH SVHC
RoHS
Schedule B
Switch Function
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Width
Description
Polyacetar, Resin, Stainless Steel
15 A
Silver
10 A
10.3 mm
1.524 mm
100 kcycles
Thermoset
51.2 mm
Production (Last Updated: 7 months ago)
15 A
80 °C
250 V
250 V
50 Mcycles
-25 °C
Chassis Mount, Screw
2
1.23 N
20.701 mm
Straight
1.5748 mm
3.9878 mm
No
IP40
Unknown
Compliant
8536509040, 8536509040|8536509040|8536509040|8536509040|8536509040
On-Mom
Quick Connect
SPDT
250 V
30 V
10.3 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹471.28
Total Price
₹471.28
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹471.28
₹471.28
10
₹394.63
₹3946.27
25
₹394.59
₹9864.78
50
₹382.55
₹19127.58
100
₹376.50
₹37649.62
