USB2514B-AEZC
Manufacturer
Microchip
Description
Microchip USB2514B-AEZC; USB Controller; 480Mbit/s; USB 2.0; 3.3 V; 36-Pin QFN
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Case/Package
Contact Plating
Data Rate
ESD Protection
Height
Interface
Lead Free
Length
Lifecycle Status
Max Operating Temperature
Max Supply Voltage
Manufacturer Package Identifier
Min Operating Temperature
Min Supply Voltage
Mount
Number of Pins
Number of Ports
Number of Transceivers
Operating Supply Current
Operating Supply Voltage
Packaging
Radiation Hardening
REACH SVHC
RoHS
Schedule B
USB Standard
Weight
Width
Description
85 °C
QFN
Tin
480 Mbps
Yes
950 µm
2-Wire, I2C, SMBus
Lead Free
6 mm
Production (Last Updated: 2 years ago)
85 °C
3.6 V
USB2514B-AEZC
0 °C
3 V
Surface Mount
36
4
3
70 mA
3.3 V
Cut Tape
No
No SVHC
Compliant
8542310000
USB 2.0
92.589543 mg
6 mm
