TPS7B6950QDBVRQ1
Manufacturer
Texas Instruments
Description
LDO Regulator Pos 5V 0.15A Automotive 5-Pin SOT-23 T/R
Datasheet
DownloadProduct Attributes
Type
Accuracy
Case/Package
Contact Plating
Dropout Voltage
Height
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Input Voltage
Max Junction Temperature (Tj)
Max Operating Temperature
Max Output Current
Max Supply Voltage
Min Current Limit
Min Input Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Supply Current
Number of Outputs
Number of Pins
Number of Regulators
Output Current
Output Type
Output Voltage
Packaging
Polarity
Quiescent Current
RoHS
Schedule B
Thickness
Width
Description
3 %
SOT-23
Tin
450 mV
1.45 mm
Lead Free
2.9 mm
Production (Last Updated: 2 days ago)
ACTIVE (Last Updated: 2 days ago)
40 V
150 °C
125 °C
150 mA
40 V
150 mA
5.5 V
-40 °C
5.5 V
Surface Mount
15 µA
1
5
1
150 mA
Fixed
5 V
Tape & Reel (TR)
Positive
15 µA
Compliant
8542390000
1.2 mm
1.6 mm
In Stock
Quantity
MOQ : 2
Per Unit Price
₹75.58
Total Price
₹151.16
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹151.16
₹151.16
10
₹48.19
₹481.95
25
₹48.23
₹1205.76
50
₹48.21
₹2410.62
100
₹39.49
₹3948.94
500
₹37.77
₹18883.05
1000
₹36.36
₹36362.06
