TAJB226K016RNJ
Manufacturer
AVX
Description
Cap Tant Solid 22uF 16V B CASE 10% (3.5 X 2.8 X 1.9mm) SMD 3528-21 2.3 Ohm 125AHA T/R
Datasheet
DownloadProduct Attributes
Type
Capacitance
Case/Package
Case Code (Imperial)
Case Code (Metric)
Depth
Dielectric Material
Dissipation Factor
ESR (Equivalent Series Resistance)
Features
Height
Height - Seated (Max)
Lead Free
Leakage Current
Length
Life (Hours)
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Pins
Packaging
Polarity
Radiation Hardening
REACH SVHC
Ripple Current
RoHS
Schedule B
Termination
Tolerance
Voltage
Voltage Rating
Voltage Rating (AC)
Voltage Rating (DC)
Width
Description
22 µF
1210
1210
3528
2.8 mm
Tantalum
6 %
2.3 Ω
General Purpose
1.9 mm
2.1082 mm
Lead Free
3.5 µA
3.5 mm
2000 hours
Production (Last Updated: 2 years ago)
ACTIVE (Last Updated: 2 years ago)
125 °C
-55 °C
PCB, Surface Mount
2
Cut Tape (CT)
Polar
No
No SVHC
192 mA
Compliant
8532210050
SMD/SMT
10 %
16 V
16 V
16 V
16 V
2.8 mm
