SRR1210-221M
Manufacturer
Bourns
Description
Inductor Power Shielded Wirewound 220uH 20% 1KHz 15Q-Factor Ferrite 1.7A 0.315Ohm DCR T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Packaging
Q Factor
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Shielding
Termination
Test Frequency
Tolerance
Weight
Width
Description
Nonstandard
Wirewound
Ferrite
8.5 A
1.7 A
1.7 A
315 mΩ
12.5 mm
10 mm
10.0076 mm
220 µH
20 %
12 mm
1.7 A
125 °C
Not
-40 °C
Surface Mount
2
Cut Tape
15
No SVHC
1.7 A
Compliant
1.5 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
1.8 MHz
Shielded
SMD/SMT
100 kHz
20 %
4.8 g
11.9888 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹121.05
Total Price
₹121.05
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹121.05
₹121.05
10
₹84.12
₹841.18
25
₹84.17
₹2104.29
50
₹84.08
₹4204.14
100
₹68.37
₹6837.06
500
₹65.17
₹32583.85
1000
₹58.45
₹58448.00
