SRP1238A-1R0M
Manufacturer
Bourns
Description
Inductor Power Shielded Wirewound 1uH 20% 100KHz 15Q-Factor Carbonyl Powder 24A 0.0035Ohm DCR Automotive T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
China RoHS
Composition
Core Material
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Lifecycle Status
Max Current Rating
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Circuits
Number of Terminals
Q Factor
Ratings
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Width
Description
Nonstandard
Compliant
Wirewound
Carbonyl Powder
24 A
24 A
3.5 mΩ
12.8 mm
3.3 mm
3.5052 mm
1 µH
20 %
13.5 mm
Production (Last Updated: 7 months ago)
24 A
24 A
150 °C
Not
-55 °C
Surface Mount
1
2
15
AEC-Q200
Yes
24 A
Compliant
40 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
40 MHz
3.5 mΩ
Yes
SMD/SMT
100 kHz
20 %
12.5 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹141.38
Total Price
₹141.38
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹141.38
₹141.38
10
₹98.79
₹987.90
25
₹98.77
₹2469.31
50
₹98.72
₹4935.95
100
₹82.66
₹8266.00
500
₹76.47
₹38236.49
1000
₹67.62
₹67620.10
