SRN6045-220M
Manufacturer
Bourns
Description
Inductor Power Semi-Shielded Wirewound 22uH 20% 100KHz 17Q-Factor Ferrite 1.5A 142mOhm DCR T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
China RoHS
Composition
Core Material
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Lifecycle Status
Material
Max Current Rating
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Circuits
Number of Pins
Number of Terminals
Packaging
Q Factor
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Weight
Width
Description
2424
Compliant
Wirewound
Ferrite
1.5 A
1.5 A
142 mΩ
6.2 mm
4.5 mm
4.4958 mm
22 µH
20 %
6 mm
Production (Last Updated: 7 months ago)
Steel
1.5 A
1.5 A
125 °C
Not
-40 °C
Surface Mount
1
2
2
Cut Tape
17
Yes
1.5 A
Compliant
1.9 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
11 MHz
142 mΩ
Yes
SMD/SMT
2.52 MHz
20 %
785.990529 mg
6 mm
In Stock
Quantity
MOQ : 3
Per Unit Price
₹44.46
Total Price
₹133.38
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹133.38
₹133.38
10
₹36.46
₹364.57
25
₹36.46
₹911.43
50
₹33.79
₹1689.46
100
₹26.23
₹2623.24
500
₹25.19
₹12594.44
1000
₹20.58
₹20584.09
