SML-LX0603SRW-TR
Manufacturer
Lumex
Description
Super Red 0603 1.6 x 0.8 mm 140 Diffused 45 mcd 1.8 V PCB Chip SMT LED
Datasheet
DownloadProduct Attributes
Type
Case/Package
Case Code (Imperial)
Case Code (Metric)
Color
Forward Current
Forward Voltage
Height
Illumination Color
Lead Free
Length
Lens Color
Lens Style
Lens Transparency
Luminous Intensity
Max Operating Temperature
Min Operating Temperature
Mount
Number of LEDs
Number of Pins
Power Dissipation
Power Rating
REACH SVHC
Reverse Voltage
RoHS
Schedule B
Test Current
Viewing Angle
Wavelength
Width
Description
0603
0603
1608
Red
20 mA
1.7 V
850 µm
Red
Lead Free
1.6 mm
White
Diffused
Diffused
15 mcd
85 °C
-40 °C
Surface Mount
1
2
44 mW
50 mW
No SVHC
5 V
Compliant
8541402000
20 mA
120 °
660 nm
800 µm
In Stock
Quantity
MOQ : Unavailable
Per Unit Price
₹Infinity
Total Price
₹Infinity
Ships in 7-10 days from Bengaluru
