S301
Manufacturer
NKK Switches
Description
Switch Toggle ON None OFF SPST Round Lever Solder Lug 20A 250VAC 30VDC Panel Mount with Threads
Datasheet
DownloadProduct Attributes
Type
Actuator Length
Actuator Material
Approvals
Contact Current Rating
Contact Material
Contact Plating
Current Rating
Depth
Electrical Life
Illumination Type
Lead Free
Length
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Min Operating Temperature
Mount
Number of Positions
Orientation
REACH SVHC
RoHS
Switch Function
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Description
17.5 mm
Brass, Chrome
CSA, UL
20 A
Silver
Silver
20 A
16 mm
25 kcycles
Illuminated, Non-Illuminated
Lead Free
28.5 mm
20 A
70 °C
250 V
30 V
-10 °C
Bushing, Panel
2
Vertical
No SVHC
Compliant
On-Off
Solder
SPST
125 V
30 V
In Stock
Quantity
MOQ : 1
Per Unit Price
₹700.09
Total Price
₹700.09
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹700.09
₹700.09
10
₹665.53
₹6655.26
25
₹638.51
₹15962.85
50
₹638.51
₹31925.70
100
₹638.51
₹63851.38
