N2514-6002RB
Manufacturer
3M
Description
Four-Wall Header 14 Position 2.54mm Solder ST Thru-Hole (ROHS)
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Gender
Contact Material
Contact Mating Length
Contact Plating
Contact Resistance
Current Rating
Depth
Flammability Rating
Gender
Height
Hole Diameter
Housing Color
Housing Material
Insulation Resistance
Lead Free
Lead Length
Lead Pitch
Length
Mating Post Length
Max Current Rating
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Poles
Number of Positions
Number of Rows
Orientation
Packaging
Pitch
Radiation Hardening
REACH SVHC
RMS Current (Irms)
RoHS
Row Spacing
Termination
Voltage Rating (AC)
Working Voltage
Description
Black
Male Pin
Male
Bronze, Gold, Nickel, Tin
6.1722 mm
Gold
20 mΩ
2 A
8.59 mm
UL94 V-0
Male
10.04 mm
890 µm
Black
Polyester
1 GΩ
Lead Free
2.84 mm
2.54 mm
25.1 mm
6.17 mm
1.75 A
105 °C
-55 °C
Through Hole
14
14
14
14
2
Straight
Bulk
2.54 mm
No
Unknown
1 A
Compliant
2.54 mm
Solder
350 V
350 V
