MMBZ5246BS-7-F
Manufacturer
Diodes Inc.
Description
Diode Zener Dual Anti Parallel 16V 5% 200mW 6-Pin SOT-363 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Forward Voltage
Height
Impedance
Lead Free
Length
Max Operating Temperature
Max Power Dissipation
Max Reverse Leakage Current
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Packaging
Peak Reverse Current
Power Dissipation
Power Rating
Radiation Hardening
RoHS
Schedule B
Termination
Test Current
Tolerance
Voltage Rating (DC)
Voltage Tolerance
Weight
Width
Zener Current
Zener Voltage
Description
SOT-363
900 mV
1 mm
17 Ω
Lead Free
2.2 mm
150 °C
200 mW
100 nA
-65 °C
Surface Mount
6
6
Tape & Reel (TR)
100 nA
200 mW
200 mW
No
Compliant
8541100050
SMD/SMT
7.8 mA
5 %
16 V
5 %
6.010099 mg
2.2 mm
100 nA
16 V
In Stock
Quantity
MOQ : 4
Per Unit Price
₹26.68
Total Price
₹106.70
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹106.70
₹106.70
10
₹17.70
₹176.95
25
₹17.71
₹442.82
50
₹17.70
₹884.75
100
₹8.74
₹874.08
500
₹8.69
₹4346.41
1000
₹8.21
₹8212.65
