MJE340
Manufacturer
STMicroelectronics
Description
Bipolar (Bjt) Single Transistor, Npn, 300 V, 20.8 W, 500 Ma, 240 Rohs Compliant: Yes
Datasheet
DownloadProduct Attributes
Type
Case/Package
Collector Base Voltage (VCBO)
Collector Emitter Breakdown Voltage
Collector Emitter Saturation Voltage
Collector Emitter Voltage (VCEO)
Contact Plating
Current Rating
Element Configuration
Emitter Base Voltage (VEBO)
Height
hFE Min
Lead Free
Length
Lifecycle Status
Max Collector Current
Max Operating Temperature
Max Power Dissipation
Min Operating Temperature
Mount
Number of Elements
Number of Pins
Polarity
Power Dissipation
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Voltage Rating (DC)
Weight
Width
Description
SOT-32
300 V
300 V
500 mV
300 V
Tin
500 mA
Single
3 V
10.8 mm
30
Lead Free
7.8 mm
Production (Last Updated: 11 months ago)
500 mA
150 °C
20 W
-65 °C
Through Hole
1
3
NPN
2.8 W
No
No SVHC
Compliant
8541290080
300 V
4.535924 g
2.7 mm
