LM1117IMP-3.3/NOPB
Manufacturer
Texas Instruments
Description
LDO Regulator Pos 3.3V 0.8A 4-Pin(3+Tab) SOT-223 T/R / IC REG LDO 3.3V 0.8A SOT223
Product Attributes
Type
Accuracy
Case/Package
Current Rating
Dropout Voltage
Height
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Input Voltage
Max Operating Temperature
Max Output Current
Max Supply Voltage
Min Current Limit
Min Input Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Output Voltage
Number of Channels
Number of Outputs
Number of Pins
Number of Regulators
Output Current
Output Type
Output Voltage
Output Voltage Accuracy
Packaging
Polarity
Quiescent Current
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Termination
Thickness
Width
Description
1 %
SOT-223
800 A
1.2 V
1.8 mm
Lead Free
6.5 mm
Production (Last Updated: 5 days ago)
ACTIVE (Last Updated: 5 days ago)
15 V
125 °C
800 mA
10 V
800 mA
2.6 V
-40 °C
4.75 V
Surface Mount
3.3 V
1
1
4
1
800 mA
Fixed
3.3 V
1 %
Cut Tape
Positive
15 mA
No
No SVHC
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
SMD/SMT
1.6 mm
3.5 mm
