KBP210G
Manufacturer
Diodes Inc.
Description
KBP210G Series 2 A 1000 V Bridge Rectifier Through Hole - KBP-4
Datasheet
DownloadProduct Attributes
Type
Average Rectified Current
Breakdown Voltage
Capacitance
Contact Plating
Current Rating
Element Configuration
Forward Current
Forward Voltage
Height
Lead Free
Length
Max Forward Surge Current (Ifsm)
Max Operating Temperature
Max Repetitive Reverse Voltage (Vrrm)
Max Surge Current
Min Operating Temperature
Mount
Number of Elements
Number of Pins
Output Current
Packaging
Peak Non-Repetitive Surge Current
Peak Reverse Current
Radiation Hardening
Reverse Voltage (DC)
RoHS
Schedule B
Termination
Voltage Rating (DC)
Width
Description
2 A
1 kV
25 pF
Tin
2 A
Single
2 A
1.1 V
10.6 mm
Lead Free
14.75 mm
65 A
150 °C
1 kV
65 A
-65 °C
Through Hole
1
4
2 A
Bulk
65 A
5 µA
No
700 V
Compliant
8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080
Through Hole
1 kV
3.65 mm
In Stock
Quantity
MOQ : 2
Per Unit Price
₹86.25
Total Price
₹172.50
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹172.50
₹172.50
10
₹43.30
₹433.04
25
₹43.30
₹1082.60
50
₹43.29
₹2164.31
100
₹43.30
₹4329.52
500
₹36.45
₹18226.82
1000
₹26.83
₹26830.72
