IHLP3232DZER5R6M11
Manufacturer
Vishay
Description
Power Choke Shielded Wirewound 5.6uH 20% 100KHz Powdered Iron 7.4A 0.0286Ohm DCR 3232 T/R Automotive AEC-Q200
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Radiation Hardening
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Description
3232
Wirewound
7.4 A
28.6 mΩ
8.26 mm
4 mm
3.9878 mm
5.6 µH
20 %
Lead Free
7.6 A
125 °C
Not
-55 °C
Surface Mount
2
No
Unknown
7.4 A
Compliant
7.6 A
8504500000, 8504500000|8504500000, 8504500000|8504500000|8504500000, 8504500000|8504500000|8504500000|8504500000
15 MHz
28.6 mΩ
Shielded
SMD/SMT
100 kHz
20 %
In Stock
Quantity
MOQ : 1
Per Unit Price
₹143.16
Total Price
₹143.16
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹143.16
₹143.16
10
₹110.71
₹1107.05
25
₹100.09
₹2502.21
50
₹92.74
₹4637.18
100
₹85.91
₹8591.45
500
₹71.87
₹35937.02
1000
₹66.52
₹66523.72
