IHLP2020BZER1R0M11
Manufacturer
Vishay
Description
Inductor Power Shielded Wirewound 1uH 20% 100KHz 7.5A 18.1mOhm DCR 2020 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Contact Plating
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Length
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Packaging
Radiation Hardening
REACH SVHC
Resistance
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Width
Description
2020
Wirewound
Tin
7.5 A
18.1 mΩ
5.43 mm
2 mm
2.0066 mm
1 µH
20 %
Lead Free
5.74 mm
7 A
125 °C
Not
-55 °C
Surface Mount
2
Tape & Reel (TR)
No
Unknown
16.8 mΩ
7.5 A
Compliant
7 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
1 MHz
18.1 mΩ
Shielded
SMD/SMT
100 kHz
20 %
5.1816 mm
