ELL-4LG6R2NA
Manufacturer
Panasonic
Description
Ind Power Choke Shielded Wirewound 6.2uH 30% 100KHz 1.1A 1515 Embossed Carrier T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Length
Lifecycle Status
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Radiation Hardening
RoHS
Saturation Current
Schedule B
Shielding
Termination
Test Frequency
Tolerance
Width
Description
1515
Wirewound
1.1 A
1.1 A
140 mΩ
4 mm
1.8 mm
1.8034 mm
6.2 µH
3.8 mm
Production (Last Updated: 1 year ago)
1.1 A
85 °C
Not
-40 °C
Surface Mount
No
Compliant
930 mA
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
Shielded
SMD/SMT
100 kHz
30 %
3.7846 mm
