BD140-16

Manufacturer

STMicroelectronics

Description

Trans GP BJT PNP 80V 1.5A 1250mW 3-Pin(3+Tab) SOT-32 Tube

Datasheet

download datasheetDownload

Product Attributes

Type

Case/Package

Collector Base Voltage (VCBO)

Collector Emitter Breakdown Voltage

Collector Emitter Saturation Voltage

Collector Emitter Voltage (VCEO)

Contact Plating

Element Configuration

Emitter Base Voltage (VEBO)

Height

hFE Min

Length

Lifecycle Status

Max Breakdown Voltage

Max Collector Current

Max Junction Temperature (Tj)

Max Operating Temperature

Max Power Dissipation

Manufacturer Package Identifier

Min Operating Temperature

Mount

Number of Elements

Number of Pins

Polarity

Power Dissipation

Radiation Hardening

REACH SVHC

RoHS

Schedule B

Width

Description

SOT-32

-80 V

80 V

-500 mV

-80 V

Tin

Single

-5 V

13.2 mm

25

7.8 mm

Production (Last Updated: 4 years ago)

80 V

-3 A

150 °C

150 °C

12.5 W

SOT-32-0016114E

-65 °C

Through Hole

1

3

PNP

1.25 W

No

No SVHC

Compliant

8541290080

2.7 mm

In Stock

Quantity

MOQ : 2

decrement quantity
increment quantity

Per Unit Price

₹64.91

Total Price

₹129.82

delivery

Ships in 7-10 days from Bengaluru

Add to List

Quantity

Unit Price

Ext. Price

1

₹129.82

₹129.82

10

₹22.62

₹226.20

25

₹22.62

₹565.50

50

₹22.62

₹1130.99

100

₹19.89

₹1989.13

500

₹16.80

₹8399.50

1000

₹13.51

₹13514.10
