90131-0122
Manufacturer
Molex
Description
2.54mm Pitch C-Grid III Header, Dual Row, Vertical, 4 Circuits, Tin (Sn) Plating
Datasheet
DownloadProduct Attributes
Type
Contact Material
Contact Plating
Country of Origin
Current Rating
Depth
Gender
Housing Color
Housing Material
Lead Free
Lead Pitch
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Circuits
Number of Contacts
Number of Positions
Number of Rows
Orientation
Pitch
Plating
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Termination
Voltage Rating
Description
Brass
Tin
SG
3 A
5.08 mm
Male
Black
Polyester
Lead Free
2.54 mm
5.08 mm
Production (Last Updated: 2 years ago)
ACTIVE (Last Updated: 2 years ago)
125 °C
-55 °C
Through Hole
4
4
4
2
Vertical
2.54 mm
Tin
No
Unknown
Compliant
8536694040, 8536694040|8536694040, 8536694040|8536694040|8536694040, 8536694040|8536694040|8536694040|8536694040
Solder
350 V
