825433-5
Manufacturer
TE Connectivity
Description
Conn Unshrouded Header HDR 5 POS 2.54mm Solder ST Thru-Hole Box
Datasheet
DownloadProduct Attributes
Type
Approvals
Color
Connector Type
Contact Current Rating
Contact Gender
Contact Material
Contact Mating Length
Contact Plating
Contact Shape
Contact Style
Current Rating
Depth
ELV
Flammability Rating
Gender
High Speed Serial Data Connector
High Temperature Housing
Housing Color
Housing Material
Insulation Resistance
Keyed
Lead Length
Lead Pitch
Length
Lifecycle Status
Manufacturer Lifecycle Status
Mating Post Length
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Poles
Number of Positions
Number of Rows
Orientation
Packaging
PCB Mounting Orientation
Pitch
Plating Thickness
Radiation Hardening
REACH SVHC
RoHS
Row Spacing
Termination
Description
CSA
Green
Header, Pin, Plug
5 A
Male
CuZn, Brass
6.7056 mm
Gold, Tin
Square
Pin
3 A
3.69 mm
Compliant
UL94 V-0
Male
No
No
Green
PBT
5 GΩ
No
3.19786 mm
2.54 mm
12.7 mm
Production (Last Updated: 1 week ago)
ACTIVE (Last Updated: 1 week ago)
6.7 mm
105 °C
-65 °C
Through Hole
5
5
5
1
Vertical
Box
Vertical
2.54 mm
2.5 µm
No
No SVHC
Compliant
2.54 mm
Through Hole
