22-03-5035
Manufacturer
Molex
Description
Conn Shrouded Header (4 Sides) HDR 3 POS 2.5mm Solder ST Top Entry Thru-Hole SPOX Bag
Datasheet
DownloadProduct Attributes
Type
Contact Gender
Contact Material
Contact Plating
Contact Resistance
Country of Origin
Current Rating
Flammability Rating
Gender
Glow Wire Compliant
Height
Housing Material
Insulation Resistance
Lead Free
Lead Pitch
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Circuits
Number of Contacts
Number of Pins
Number of Poles
Number of Positions
Number of Rows
Orientation
Packaging
Pitch
Plating
Radiation Hardening
REACH SVHC
RoHS
Shrouded
Termination
Test Voltage
Voltage Rating
Voltage Rating (AC)
Voltage Rating (DC)
Width
Working Voltage
Description
Male
Brass
Tin
20 mΩ
TW
3 A
UL94 V-0
Male
Non-compliant
5.9 mm
Nylon
1 GΩ
Lead Free
2.5 mm
9.9 mm
Production (Last Updated: 2 years ago)
ACTIVE (Last Updated: 2 years ago)
105 °C
-40 °C
PCB, Through Hole
3
3
3
3
3
1
Vertical
Bulk
2.5 mm
Tin
No
Unknown
Compliant
Yes
Solder
1 kV
250 V
250 V
250 V
4.9 mm
250 V
In Stock
Quantity
MOQ : 4
Per Unit Price
₹28.28
Total Price
₹113.12
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹113.12
₹113.12
10
₹17.43
₹174.28
25
₹17.37
₹434.37
50
₹17.39
₹869.64
100
₹14.81
₹1481.41
500
₹12.84
₹6419.14
1000
₹10.88
₹10878.47
