1N4148W-13-F
Manufacturer
Diodes Inc.
Description
Rectifier Diode Small Signal Switching 100V 0.3A 4ns 2-Pin SOD-123 T/R
Datasheet
DownloadProduct Attributes
Type
Average Rectified Current
Capacitance
Case/Package
Element Configuration
Forward Current
Forward Voltage
Height
Lead Free
Length
Max Forward Surge Current (Ifsm)
Max Junction Temperature (Tj)
Max Operating Temperature
Max Repetitive Reverse Voltage (Vrrm)
Max Reverse Voltage (DC)
Max Surge Current
Min Operating Temperature
Mount
Number of Pins
Peak Non-Repetitive Surge Current
Peak Reverse Current
Power Dissipation
Power Rating
Radiation Hardening
Recovery Time
Reverse Recovery Time
Reverse Voltage
RoHS
Schedule B
Weight
Width
Description
150 mA
2 pF
SOD-123-2
Single
300 mA
1.25 V
1.45 mm
Lead Free
2.85 mm
1 A
150 °C
150 °C
100 V
100 V
2 A
-65 °C
Surface Mount
2
2 A
1 µA
400 mW
400 mW
No
4 ns
4 ns
100 V
Compliant
8541100070, 8541100070|8541100070|8541100070|8541100070|8541100070
10.007382 mg
1.7 mm
