1988820
Manufacturer
Phoenix Contact
Description
Conn PC Terminal Block 4 POS 5mm Solder Thru-Hole 17.5A
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Approvals
Color
Contact Material
Current
Current Rating
Depth
Flammability Rating
Gender
Height
Housing Color
Housing Material
Lead Free
Length
Material
Max Current Rating
Max Operating Temperature
Max Supply Voltage
Min Operating Temperature
Mount
Number of Circuits
Number of Contacts
Number of Levels
Number of Pins
Number of Poles
Number of Positions
Number of Positions Per Level
Number of Rows
Orientation
Packaging
Pitch
Radiation Hardening
RoHS
Termination
Voltage
Voltage Rating
Weight
Width
Wire Gauge (Max)
Wire Gauge (Min)
Description
100 °C
CB, UL, VDE
Green
Tin
15 A
17.5 A
12.8 mm
UL94 V-0
Male
12.05 mm
Green
Polyamide
Lead Free
20 mm
Polyamide
24 A
100 °C
250 V
-40 °C
Through Hole
4
4
1
4
4
4
4
1
Straight
Bulk
5 mm
No
Compliant
Solder
300 V
250 V
4.120008 g
20 mm
26 AWG
12 AWG
