1735446-8
Manufacturer
TE Connectivity
Description
1735446 Series; 2mm Pitch 8 Way 1 Row Straight PCB Header; Solder Termination
Datasheet
DownloadProduct Attributes
Type
Color
Connector System
Connector Type
Contact Current Rating
Contact Gender
Contact Mating Length
Contact Plating
Contact Shape
Contact Style
Current Rating
ELV
Flammability Rating
Height
Housing Color
Housing Material
Lead Length
Length
Lifecycle Status
Manufacturer Lifecycle Status
Mating Post Length
Mating Retention
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Positions
Number of Rows
Operating Supply Voltage
Orientation
Packaging
PCB Mount Alignment
PCB Mounting Orientation
PCB Mount Retention
PCB Thickness
Pitch
Plating
Plating Thickness
Radiation Hardening
RoHS
Sealable
Tail Length
Termination
Width
Wire/Cable Gauge
Wire/Cable Type
Description
Natural
Wire-to-Board
Header, Pin, Plug
3 A
Male
3.3528 mm
Tin
Square
Pin
3 A
Compliant
UL94 V-0
6.0706 mm
Natural
Thermoplastic
3.4036 mm
18.00098 mm
Production (Last Updated: 6 days ago)
ACTIVE (Last Updated: 6 days ago)
3.3274 mm
With
85 °C
-25 °C
Through Hole
8
8
1
250 V
Vertical
Bulk
Without
Vertical
With
1.6 mm
2.0066 mm
Tin
2.03 µm
No
Compliant
No
3.4 mm
Through Hole
4.7 mm
30 AWG
Discrete
